1.

Physical Pixel Pitch

10 mm

2.

Physical Pixel Density

10000 dots/m²

3.

Pixel composition

1Red, 1Green,1Blue

4.

Cabinet Depth

< 160 mm

5.

Cabinet Style

Normal outdoor  Cabinet

6.

Brightness

≥7000 nits

7.

Driving Method

1/4 scan

8.

Brightness Control

Red, Green and Blue 4096 Grade/Each

9.

Colors

16.7million

10.

Viewing angle

Horizontal ≥120°,   Vertical  : ≥  45°

11.

Viewing distance

10m – 150 m

12.

Scan frequency

≥2000Hz

13.

Video Frame Rate

≥120 fps

14.

Color temperature

6500°K to 9500°K adjustable

15.

Control method

Controlled by PC, synchronous display

16.

Defects Rate

≤0.00001

17.

Continual

operating period

≥24 hours

18.

MTBF

≥10,000 hours

19.

Life span

( half brightness)

≥100,000 hours

20.

Level up degree

≤±1mm

21.

Protective Grade

IP65

22.

Weight

65Kg / m²

23.

Average

power consumption

375 W/ m²

24.

Peak

power consumption

750W/ m²

25.

Input voltage

AC220V/50Hz ±10%    or  AC110V/60Hz ±10%

26.

Operating Environment

Temperature:-20℃－+60℃      Humidity:10%－95%RH

27.

Operating system

Windows 98/2000/ME/XP
