1.

Cabinet Style

Normal outdoor Cabinet

2.

Brightness

≥6800 nits

3.

Driving Method

static

4.

Brightness Control

Red, Green and Blue 4096 Grade/Each

5.

Colors

16.7million

6.

Viewing angle

Horizontal ≥120°,   Vertical   ≥  45°

7.

Viewing distance

16m – 120 m

8.

Color temperature

6500°K to 9500°K adjustable

9.

Defects Rate

≤0.00001

10.

Continual

operating period

≥24 hours

11.

MTBF

≥10,000 hours

12.

Life span

( half brightness)

≥100,000 hours

13.

Level up degree

≤±1mm

14.

Protective Grade

IP65

15.

Cabinet material

Iron

16.

Weight

50Kg / m²

17.

Average

power consumption

439W/ m²

18.

Peak

power consumption

878W/ m²

19.

Input voltage

AC220V/50Hz ±10%    or  AC110V/60Hz ±10%

20.

Operating Environment

Temperature:-20℃－+60℃      Humidity:10%－95%RH

21.

Operating system

Windows 98/2000/ME/XP

22.

Type of video signal

S-video, composite video ,RGB ,VGA ,DVI
