No.

Specifications

Project

1.

Physical Pixel Pitch

3mm

2.

Physical Pixel Density

111111dots/m²

3.

Contrast rate

1000:1

4.

Brightness difference between close pixel

≦5%

5.

Brightness difference between close cabinet

≦3%

6.

Pixel composition

1Red, 1Green,1Blue

7.

Cabinet Depth

<60 mm

8.

Brightness

≥2000 nits

9.

Grey level

4096  grade

10.

Colors

16.7million

11.

Viewing angle

Horizontal ≥120°,   Vertical  : ≥ 120°

12.

Viewing distance

3m –20m

13.

Scan frequency

≥300Hz

14.

Video Frame Rate

≥120 fps

15.

Color temperature

6500°K to 9500°K adjustable

16.

Continual

operating period

≥24 hours

17.

MTBF

≥10,000 hours

18.

Life span

( half brightness)

≥100,000 hours

19.

Level up degree

≤±1mm

20.

Average

power consumption

520 W/ m²

21.

Peak

power consumption

1300W/ m²

22.

Input voltage

AC220V/50Hz ±10%    or  AC110V/60Hz ±10%

23.

Operating Environment

Temperature:-20℃－+60℃      Humidity:10%－95%RH

24.

Operating system

Windows 98/2000/ME/XP

25.

Type of video signal

S-video, composite video ,RGB ,VGA ,DVI
